MIMAKI UCJV330-130 – RECOLOR PRINTER

UCJV330-130 UV Printer

UCJV300 Series Printer is a multifunctional inkjet printer equipped with UV curing ink and capable of printing and cutting.

2 Pcs Print Heads
Max. Printing Size 1360 mm (53.5 in)
LUS-170 / LUS-175 / LUS-190 / LUS-200 / LUS-210

Contact us for shipping, installation, tariffs and warranty..

Printing Speed

UCJV330-130 Printer 4C printing

Model	Resolution	Pass	Printing Speed (m2/h）
Draft	600×600dpi	4	40
High Speed	600×600dpi	6	28
Standard	600×1200dpi	8	20
Quality	1200×1200dpi	12	11
High Quality	1200×1800dpi	16	8

UCJV330-130 Printer 6Color+SP/4Color+SP printing

Model	Resolution	Pass	Printing Speed (m2/h）
High Speed	600×600dpi	10	18
Standard	600×1200dpi	16	10
Quality	1200×1200dpi	16	6.3
High Quality	1200×1800dpi	24	3.7

UCJV330-130 Printer 4/6Color +White 2 layers printing

Model	Resolution	Pass	Printing Speed (m2/h）
High Speed	600×600dpi	10	9
Standard	600×1200dpi	16	5
Quality	1200×1200dpi	16	3.2
High Quality	1200×1800dpi	24	1.5

UCJV330-130 Printer 4/6Color +White 3 layers printing

Model	Resolution	Pass	Printing Speed (m2/h）
High Speed	600×600dpi	10	6
Standard	600×1200dpi	16	3.3
Quality	1200×1200dpi	16	2.1
High Quality	1200×1800dpi	24	1.2

UCJV330-130 Printer 4/6Color +White 5 layers printing

Model	Resolution	Pass	Printing Speed (m2/h）
Standard	600×1200dpi	16	2.0
Quality	1200×1200dpi	16	1.3
High Quality	1200×1800dpi	24	0.7

MIMAKI Technology

Ink Color Configuration

Benefits & Features

Mimaki UV flagship model, featuring high image quality, high throughput and application versatility

The “UCJV330 Series” is a print and cut UV-LED inkjet printer that combines the high productivity and high image quality of our flagship “330 Series” with UV printing technology, significantly improving productivity and image quality compared to previous models.

Product Overview

This flagship model not only boasts high image quality and high productivity, but also features Mimaki’s exclusive advanced UV-LED technology.
This model not only inherits traditional 2- to 5-layer printing capabilities but is also Mimaki’s first roll-to-roll product to support 2.5D printing.
This model is equipped with unique features such as Mimaki’s exclusive watermark printing to meet a variety of needs.
With ultimate image quality, elevate your logos and graphics to new heights, adding value to your business.

“Multi-layer Printing” offers a new advertising expression.

4-layer printing (Day/Night printing)
5-layer printing (Front/Reverse printing)

On-demand printing leveraging UV characteristics

UV ink characteristics enable quick transition to next-step processing and label application
Wide range of applications

Newly developed eco-friendly UV inks [LUS-170] , [LUS-175], [LUS-190], [LUS-210]

New transparent ink!

Flexible UV ink [LUS-200]

Efficient cutting capabilities. The newly added [ID Cutting] feature significantly improves work efficiency.

Upgraded RIP software [RasterLink 6 Plus] and [RasterLink 7]

Print widths up to 1360 mm.
With a compact footprint and versatile features, it’s suitable for producing a wide range of stickers, labels, and point-of-sale materials.

Core Technologies:

Waveform Control
Mimaki Advanced Pass System
Nozzle Check Unit
Nozzle Recovery System
Mimaki Circulation Technology
Mimaki Fine Diffusion

Printing Materials:

PET ♦Vinyl ♦PVC ♦Backlit ♦Canvas ♦Advertising ♦Wallpaper ♦Decoration

Specifications

Item	UCJV330-130
Print head	2 Pcs Print Heads
Printing resolution	Y: 600 dpi, 1200 dpi, X: 600 dpi, 1200dpi, 1800 dpi
Ink Type/color	LUS-170/ LUS-175/ LUS-190/ LUS-200/ LUS-210
Media thickness	1mm or less
Interface	USB2.0/Ethernet
Power supply	Single phase AC100-240V, ±10%, 18A, 50/60Hz ±1Hz
Power consumption	1,440W or less
Operation environment	20°C to 30°C (68°F to 86°F)/35 to 65% RH (No condensation)
RIP Software	RasterLink7
External dimensions (W × D × H)	2,640× 800 × 1,480 mm/ 103.9 × 31.5 × 58.3 in
Weight	217 kg / 478.4 lb
